If you are applying for a residential building permit in City of Windsor, the site plan should be built from reliable property information, not a guess at the lot lines. City of Windsor's residential permit checklist asks for survey property lines, property dimensions, compass orientation, adjacent roads, easements, and the location of existing and proposed buildings or structures.
This guide explains how to draw a site plan for a building permit in City of Windsor, what to include for common residential projects, and how to use a survey as the base for a cleaner permit drawing.
What is a site plan?
Site plan definition
A site plan is a top-down drawing of your property. It shows the legal lot, nearby roads, existing buildings, proposed work, easements, dimensions, and the distances from buildings or structures to property lines.
For a homeowner, a site plan for property shows where the work will happen. A site plan for a building permit helps City of Windsor review additions, accessory buildings, decks, porches, pools, alterations, repairs, basement renovations, parking, vehicle access, and fire access details when those items apply to the project.
Common site plan terminology
| Term | Plain-English meaning | Example |
|---|---|---|
| Setbacks | The distances from an existing or proposed building, deck, porch, pool, or accessory structure to the property lines. |  Setback example |
| Existing buildings and structures | Buildings and structures already on the property, such as the house, garage, deck, porch, driveway, pool, or accessory building. |  Existing structures example |
| Proposed buildings and structures | New work you want approval for, such as an addition, deck, porch, replacement porch, accessory building, or pool. |  Proposed structures example |
| Dimensions | Measurements written on the drawing, including property dimensions, building dimensions, proposed work size, parking dimensions, vehicle access dimensions, and distances to property lines. |  Site plan dimensions example |
| Lot lines or property lines | The surveyed edges of the property. City of Windsor asks the site plan to show survey property lines. |  Property line example |
| Easement | A part of the property where another party may have a legal right to use or access the land. Show easements that appear on the survey or other property records. |  Easement example |
Do you need a site plan?
City of Windsor's residential permit materials list a site plan for residential permits, including alterations, additions, accessory buildings, basement renovations, repairs, decks, porches, replacement porches, and pools.
The site plan matters most when the project changes the outside of the property or affects access, parking, lot coverage, fire access, easements, or the distance to property lines. For an interior-only project such as a basement renovation, confirm the current submission requirements with City of Windsor if the online permit instructions are unclear, but be prepared to provide a site plan when the permit package asks for one.
Create a site plan for free using HomeCat that gets your building permit approved in City of Windsor. Get started
Site plan requirements for building permits in City of Windsor
A City of Windsor site plan should include the property information and project details the reviewer needs to locate the work. For residential permits, prepare the drawing to show:
- Legal description
- Survey property lines
- Property dimensions
- Compass orientation
- Location and name of adjacent roads
- Easements
- Key plan
- Outline of all existing buildings and structures
- Outline of all proposed buildings and structures
- Building dimensions
- Distances from buildings and structures to property lines
- Parking and vehicle access dimensions and locations, when relevant
- Fire routes, hydrants, and fire department connection locations, when relevant
- Barrier-free parking, barrier-free curbs, ramps, path of travel, building access, loading spaces, bicycle spaces, and refuse areas, when relevant to the project
Additions, decks, porches, and replacement porches
For exterior work attached to the house, show the existing house, the proposed addition, deck, porch, or replacement porch, and the closest property lines. Add the dimensions of the proposed work and the distances from the proposed work to the side, rear, and front property lines as applicable.
If the work affects stairs, landings, driveway access, parking, ramps, or the path to the building entrance, show those items on the same site plan so City of Windsor can review the full site impact.
Accessory buildings and pools
For an accessory building or pool, show the surveyed property lines, house, existing structures, proposed structure or pool, easements, adjacent roads, and all relevant dimensions. Write the proposed building or pool size directly on the drawing and add setbacks to nearby property lines and nearby structures.
If the pool or accessory building affects parking, vehicle access, fire routes, hydrants, drainage features shown on the survey, or an easement, label those items clearly.
Alterations, repairs, and basement renovations
For work that does not obviously change the outside of the property, the site plan can be simpler. It should still identify the property, adjacent road, house, and work area if City of Windsor asks for a site plan as part of the permit package. If the alteration or repair changes an entrance, parking area, ramp, loading area, exterior wall, addition, porch, deck, or other site feature, include the same dimensions and property-line context you would include for exterior work.
(With Survey) How to draw a site plan using a survey for City of Windsor
Use a property survey as the base drawing when preparing a City of Windsor site plan. City of Windsor asks for survey property lines, property dimensions, adjacent roads, easements, and building distances, so a survey is the best starting point for a permit-ready drawing.
If you do not have a survey, check your closing documents first. You can also ask your lawyer, closing agent, or mortgage company. If needed, City of Windsor directs homeowners to submit a Freedom of Information request through the City of Windsor's Freedom of Information process.
Online maps and aerial screenshots can help you think through the project, but they should not replace the survey-based site plan when the permit package asks for surveyed property lines.
1. Print your survey, and get an extra blank piece of paper
Print the survey at a readable size. If possible, keep the scale intact. Get a blank sheet of paper, tracing paper, or a transparent digital layer if you are working on a tablet.
Do not mark up your only original copy. Work on a copy so you can start over if needed.
Example property survey to use as the base drawing
Blank paper, ruler, and pen for drawing over a survey
2. Trace the property details City of Windsor expects
Trace the surveyed property boundary, property dimensions, north arrow or compass orientation, adjacent road name, house footprint, existing structures, and easements. Add a key plan if your permit package needs one.
Also carry over any survey information that affects where the work can go, such as easements, rights noted on the plan, drainage features, or existing structures close to the project area.
Survey details traced by hand
3. Draw the proposed work
Draw the proposed addition, deck, porch, replacement porch, accessory building, pool, alteration area, or other work on the copied survey. Label it clearly as proposed.
Use a darker line, different color, or dashed outline so the reviewer can immediately separate proposed work from existing buildings and structures.
4. Add dimensions, setbacks, parking, and access details
Write the dimensions of the proposed work directly on the drawing. Add distances from existing and proposed buildings or structures to the nearest property lines.
For projects that affect the driveway, parking, access route, ramp, fire route, hydrant, building access, loading area, bicycle parking, refuse area, or barrier-free path of travel, show the dimensions and location of those items as well.
Proposed structures drawn on traced survey
Create a site plan for free using HomeCat that gets your building permit approved in City of Windsor. Get started
Site plan examples for permit for City of Windsor
The most useful site plan example for a City of Windsor permit is a clean survey copy marked up with the proposed project. Use the survey as the base, then add only the project-specific information the reviewer needs.
For a deck or porch, the drawing should make the house, proposed deck or porch, property lines, road side, and setbacks easy to read. For an accessory building or pool, it should show the structure or pool location, dimensions, nearby buildings, easements, and distances to property lines. For work that affects parking or access, it should show the driveway, parking area, route to the building, and any relevant barrier-free or fire access details.
Common site plan mistakes that delay your building permit in City of Windsor
Using approximate property lines
City of Windsor asks for survey property lines. Aerial photos, online maps, and fence lines can be useful for planning, but they are not a substitute for surveyed property lines when you prepare the permit site plan.
Missing orientation or adjacent roads
Add a compass orientation and the name and location of adjacent roads. This helps the reviewer understand which side is the front yard and how the work relates to the street.
Missing building dimensions and setbacks
Show the dimensions of existing and proposed buildings or structures and write the distances to property lines. The reviewer should not have to calculate the proposed location from an unlabeled sketch.
Leaving out easements, parking, access, or fire details
If an easement, parking area, vehicle access route, fire route, hydrant, fire department connection, ramp, building access route, loading space, bicycle space, or refuse area applies to the project, show it on the site plan. These details can affect whether the proposed work fits on the site.
Frequently asked questions about site plans
Can homeowners prepare and submit their own drawings in City of Windsor?
Yes. In Ontario, homeowners can generally prepare drawings for a house they own. The drawings still need to be clear enough for permit review, and City of Windsor can require more detail or a qualified professional when the project is complex, engineered, or outside the usual homeowner design exemption.
What if City of Windsor asks me to fill out a Schedule 1: Designer Information form?
For homeowner-prepared drawings in Ontario, the Schedule 1 form usually identifies the design activity as House. In the project description, describe the work, such as deck, porch, pool, addition, or accessory building.
Under the designer declaration, choose the option stating that the design work is exempt from the registration and qualification requirements of the Building Code. For the basis of exemption, enter Homeowner.
Where can I get a legal property survey in City of Windsor?
Start with the documents from when you bought the property. If you cannot find a survey there, ask your lawyer, closing agent, title insurer, or mortgage company. City of Windsor also points homeowners to the City of Windsor Freedom of Information process for requesting property survey records through MFIPPA.
Read our Ontario ultimate guide for getting a property survey before paying for a new survey.
Does my survey need to be recent?
For many residential permit drawings in Ontario, an older survey prepared by a licensed Ontario Land Surveyor can still be useful if it accurately shows the property lines and existing conditions used for the site plan. If the property has changed since the survey, update the site plan to show current buildings, structures, parking, access, and proposed work.
What if City of Windsor rejects my site plan?
Use the review comments as a checklist. Add the missing survey property lines, property dimensions, compass orientation, adjacent road name, easement, key plan, building dimensions, setbacks, parking, vehicle access, fire access, barrier-free route, or other item City of Windsor requested.
When you resubmit, make the revisions easy to find and keep the site plan consistent with the permit application and the rest of your drawings.
Conclusion
A good beginner site plan does not need to be complicated. It needs to show the surveyed property, the existing conditions, the proposed work, and the measurements that matter for your building permit in City of Windsor.
