If you are applying for a building permit in Town of Oakville, the site plan needs to make the project location clear enough for review. Town of Oakville's deck guidance asks the drawing to show the house, porch, exterior stairs, accessory buildings, deck, pool, driveway, walkways, patios, setbacks, and deck dimensions when those items apply.
This guide explains how to draw a site plan for a building permit in Town of Oakville, with practical notes for decks, sheds, cabanas, gazebos, and other small residential projects that need a clear property drawing.
What is a site plan?
Site plan definition
A site plan is a scaled or clearly dimensioned drawing of your property from above. It shows the lot, the existing house and structures, the proposed work, and the measurements that explain where everything sits.
For a homeowner, a site plan for property is the drawing that connects your project to the actual lot. A site plan for a building permit helps Town of Oakville review the proposed location, the relationship to the house and other structures, the setbacks to property lines, hard landscape surfaces, and whether the drawing gives enough context for the permit type.
For a deck in Town of Oakville, the site plan should not show only the new deck. It should also show nearby existing conditions such as the porch, exterior stairs, accessory buildings, pool, driveway, walkways, and patios when they apply.
Common site plan terminology
| Term | Plain-English meaning | Example |
|---|---|---|
| Setbacks | The distances from a proposed deck, shed, cabana, gazebo, or other structure to the property lines. |  Setback example |
| Existing buildings and structures | Things already on the property, including the house, porch, exterior stairs, shed, garage, deck, pool, driveway, walkway, or patio. |  Existing structures example |
| Proposed buildings and structures | New work you want approved, such as a proposed deck, shed, cabana, gazebo, porch, or stair. |  Proposed structures example |
| Dimensions | Measurements written on the drawing, including the size of the proposed work and key distances to property lines or existing features. |  Site plan dimensions example |
| Lot lines or property lines | The legal edges of the property. These are the lines used when checking setbacks. |  Property line example |
Do you need a site plan?
You usually need a site plan when an Town of Oakville building permit project adds or changes something with a location on the property. Town of Oakville specifically points to a site plan for sheds, cabanas, and gazebos, and its deck guidance includes a detailed site plan checklist.
For decks, the site plan should show the proposed deck in relation to the house and property lines. It should also include surrounding site features that affect the review, such as accessory buildings, pools, driveways, walkways, and patios.
For sheds, cabanas, and gazebos, use the same basic approach: show where the proposed structure sits on the lot, add dimensions, and include the existing house, property lines, nearby structures, and setbacks.
Create a site plan for free using HomeCat that gets your building permit approved in Town of Oakville. Get started
Site plan requirements for building permits in Town of Oakville
The exact site plan requirements in Town of Oakville depend on the project. For a deck, the drawing should include the main property features and the measurements that show the deck location clearly.
At minimum, a useful Town of Oakville site plan usually shows:
- Property lines
- House, including porch and exterior stairs
- Accessory buildings, such as a shed or garage
- Proposed deck, shed, cabana, gazebo, or other work
- Pool location, if applicable
- Driveway
- Walkways and patios
- Setbacks from the proposed work to property lines
- Distance from the rear wall of the house to the rear property line for deck projects
- Dimensions of the proposed work
Use the Town of Oakville permit page for your specific project first. If the local instructions only say "site plan," include the core property outline, existing structures, proposed structure, dimensions, and setbacks so the reviewer can understand the location without guessing.
Decks
For a deck, show the house, including the porch and exterior stairs. Add accessory buildings such as a shed or garage, the proposed deck, any pool, driveway, walkways, and patios when those features apply.
Add the deck dimensions, the setbacks from the deck to the property lines, and the distance from the rear wall of the house to the rear property line. These measurements make it easier for Town of Oakville to review the deck location and rear-yard context.
Deck Site plan example in Town of Oakville
Sheds, cabanas, and gazebos
For a shed, cabana, or gazebo, the site plan should focus on the proposed structure's location on the lot. Show the property lines, existing house, existing accessory buildings, the proposed structure, its dimensions, and the setbacks to nearby property lines.
If the structure is close to a pool, patio, driveway, walkway, fence, easement, or another building, add enough context to show the relationship clearly.
(Without Survey) How to draw a site plan by hand for Town of Oakville
For simple Town of Oakville projects where a survey is not required by the permit instructions, a clean hand-drawn site plan can be a practical starting point. Use a ruler, keep the drawing readable, and write the important measurements directly on the plan.
If your project is close to a property line, if the lot shape is unclear, or if you need reliable legal boundary information, use a property survey instead of guessing from fences, landscaping, or online maps.
1. Draw the footprint of your house
Start with the outside shape of the house. Add the porch and exterior stairs if they are on the side of the house near the project.
Label the house as existing and add the property address.
House footprint drawn by hand
2. Draw your property boundary
Draw the property lines around the house. If you do not have a survey, label the boundary as approximate unless you have confirmed the legal lot lines another way.
Leave enough room around the rear yard and side yards to write setback measurements.
Property boundary drawn by hand
3. Draw the main street along your property
Add the street at the front of the lot and write the street name. If the property is on a corner, show both streets so the front and side yards are clear.
Main street drawn on hand site plan
4. Label the rear of your property
For a deck, make the rear-yard relationship easy to read. Label the rear property line and add the distance from the rear wall of the house to the rear property line.
Rear yard labeled on hand site plan
5. Draw existing and proposed structures
Add the existing features Town of Oakville asks for when applicable: accessory buildings, pool, driveway, walkways, patios, porch, exterior stairs, and nearby structures.
Draw the proposed deck, shed, cabana, or gazebo with a darker outline or different line style. Label it clearly as proposed.
Existing and proposed structures drawn by hand
6. Measure setbacks, proposed, and existing structures
Write the size of the proposed work on the plan. Then add the setbacks from the proposed work to the nearest property lines.
For a deck, include the deck dimensions, deck-to-property-line setbacks, and the rear-wall-to-rear-property-line measurement. If the deck is near a pool, patio, stairs, shed, garage, walkway, or driveway, add the measurements that explain the relationship.
Measurements added to hand-drawn site plan
(With Survey) How to draw a site plan using a survey for Town of Oakville
If you have a property survey, use it as the base for your Town of Oakville site plan. A survey is especially useful when the proposed work is close to a lot line, when the property shape is not obvious, or when you need reliable locations for existing buildings, property boundaries, or easements.
If you do not have a survey, check your closing documents, ask your real estate lawyer, closing agent, or mortgage company, or request a property survey through the Town of Oakville routine disclosure request process. You can also read our guide for getting a property survey in Ontario before paying for a new one.
1. Print your survey, and get an extra blank piece of paper
Print the survey at a readable size. If possible, keep the scale intact. Get a blank sheet of paper, tracing paper, or a transparent digital layer if you are working on a tablet.
Do not mark up your only original copy. Work on a copy so you can start over if needed.
Example property survey to use as the base drawing
Blank paper, ruler, and pen for drawing over a survey
2. Place the paper over, and trace important details
Trace the property boundary, house footprint, street, north arrow if shown, existing setback measurements, and existing structures near the project.
For a deck, also trace or add the porch, exterior stairs, accessory buildings, pool, driveway, walkways, patios, rear wall of the house, and rear property line when those items apply.
Survey details traced by hand
3. Draw your proposed structures and add measurements and setbacks
Draw the proposed deck, shed, cabana, or gazebo on the survey copy or traced base. Label it as proposed and write the proposed dimensions clearly.
Add the setbacks from the proposed work to the property lines. For decks, include the distance from the rear wall of the house to the rear property line so Town of Oakville can review the rear-yard context quickly.
Proposed structures drawn on traced survey
Create a site plan for free using HomeCat that gets your building permit approved in Town of Oakville. Get started
Site plan examples for permit for Town of Oakville
Town of Oakville provides a deck site plan example. Use it as a format guide for the level of detail to show: the house, accessory buildings, deck, pool, hard landscape surfaces, setbacks, and dimensions.
Deck Site plan example in Town of Oakville
For sheds, cabanas, and gazebos, copy the same clear layout style. Show the proposed structure on the property, label it, add its dimensions, and show the setbacks to property lines.
Common site plan mistakes that delay your building permit in Town of Oakville
Most Town of Oakville site plan delays come from drawings that show the new work but leave out the surrounding property context or measurements.
Missing nearby existing structures
Do not draw the proposed deck, shed, cabana, or gazebo by itself. Show the house and the nearby existing features that affect the project area, including the porch, exterior stairs, accessory buildings, pool, driveway, walkways, and patios when they apply.
Missing setback measurements
Add the distances from the proposed work to the nearest property lines. For deck projects, include the setbacks from the deck to the property lines and the distance from the rear wall of the house to the rear property line.
Missing hard landscape surfaces
Town of Oakville's deck guidance includes driveways, walkways, and patios in the site plan checklist. Show these hard landscape surfaces when they are on the property and relevant to the proposed work.
Not enough detail about the proposed work
Label the proposed work and write its dimensions. The reviewer should not have to infer whether a shape is a deck, shed, cabana, gazebo, porch, stair, patio, or existing structure.
Frequently asked questions about site plans
Can homeowners prepare and submit their own drawings in Town of Oakville?
Yes. In Ontario, homeowners can generally prepare drawings for a house they own because the Ontario Building Code exempts design work for "a house owned by the person" from the usual designer qualification requirements under Division C, Article 3.2.5.1.(3)(b)(i). Town of Oakville can still require drawings to be clear, measured, and complete enough for building permit review.
What if Town of Oakville asks me to fill out Schedule 1: Designer Information?
For "Design activities undertaken by individual identified in Section B," select House. In the description, enter the actual project, such as "deck," "shed," "cabana," or "gazebo."
Under "Declaration of Designer," choose The design work is exempt from the registration and qualification requirements of the Building Code. For "Basis for exemption from registration and qualification," write Homeowner.
Where can I get a legal property survey in Town of Oakville?
Start with your closing documents, then ask your real estate lawyer, closing agent, or mortgage company. If you still cannot find one, request a property survey through the Town of Oakville routine disclosure request process.
Read our Ontario ultimate guide for getting a property survey before ordering a new survey.
Does my survey need to be recent?
An older survey prepared by a licensed Ontario Land Surveyor can still be useful if it accurately shows the property boundaries and existing conditions. Update the site plan so it reflects the property today, including current decks, sheds, garages, pools, driveways, walkways, patios, porch areas, exterior stairs, and the proposed work.
If the survey does not match the current property or your project depends on exact setbacks, ask Town of Oakville what it will accept before submitting.
Can I use Google Maps for my Town of Oakville site plan?
Use Google Maps only for early planning. It can help you understand the general lot layout, but it does not provide legal property lines. For the permit drawing, use a measured hand drawing or a survey-based site plan with the required structures, hard surfaces, dimensions, and setbacks.
What if Town of Oakville rejects my site plan?
Read the review comments and revise the drawing to answer each one directly. Common fixes include adding missing deck dimensions, deck-to-property-line setbacks, the rear-wall-to-rear-property-line measurement, accessory buildings, pool location, driveway, walkways, patios, porch details, exterior stairs, or clearer labels.
When do I need a professional drawing?
You may need professional help when the project is structural, engineered, complex, close to a property line or easement, or when Town of Oakville specifically requires it. For the site plan portion of a straightforward deck, shed, cabana, or gazebo permit, start with the Town of Oakville checklist and a clear drawing based on reliable property measurements.
Conclusion
A good beginner site plan for Town of Oakville is a clear property drawing that shows the existing conditions, proposed work, and measurements that matter for your building permit. For decks, make the house, porch, exterior stairs, accessory buildings, pool, hard landscape surfaces, deck dimensions, setbacks, and rear-yard measurement easy to find.
