If you are applying for a residential building permit in City of Brampton, your site plan often needs to be prepared with a legal property survey. City of Brampton permit packages specifically call for site plans and legal property surveys for decks, porches, carports, garages, additions, interior alterations, below grade entrances, and some pool enclosure applications.
This guide explains how to draw a site plan for a residential building permit in City of Brampton, what details to include for common projects, and how to use a survey as the base for your permit drawing.
What is a site plan?
Site plan definition
A site plan is a scaled or clearly dimensioned drawing of your property from above. It shows the property lines, existing buildings, proposed work, and the distances between the proposed work, lot lines, and other buildings.
For a homeowner, the easiest way to think about it is this: a site plan for property shows what is already on the lot and what you want to add or change. A site plan for a residential building permit helps City of Brampton review the proposed location, dimensions, setbacks, pool enclosure, grading, and relationship to other buildings.
Because City of Brampton frequently asks for a legal property survey, do not rely on an approximate map screenshot when the checklist for your project says a survey must accompany the site plan.
Common site plan terminology
| Term | Plain-English meaning | Example |
|---|---|---|
| Setbacks | The distances from a structure or proposed structure to the property lines. |  Setback example |
| Existing buildings and structures | Things already on the property, such as the house, garage, deck, shed, driveway, porch, pool, patio, or fence. |  Existing structures example |
| Proposed buildings and structures | New items you want approval for, such as a proposed deck, porch, garage, carport, pool, cabana, shed, gazebo, or below grade entrance. |  Proposed structures example |
| Dimensions | Measurements written directly on the drawing, including the size of the proposed work and distances to property lines and buildings. |  Site plan dimensions example |
| Lot lines or property lines | The legal edges of your property. These are the lines reviewers use when checking setbacks. |  Property line example |
| Easement | A part of your property where another person, utility, municipality, or other party has a limited legal right to use or access the land for a specific purpose. |  Easement example |
| Lot grading | The shape and slope of the land that controls where water drains on the property. |  Lot grading example |
Do you need a site plan?
You usually need a site plan when your City of Brampton project adds or changes something with a fixed location on the lot. City of Brampton checklists refer to site plans for accessory structures, decks, patios, porches, porch enclosures, residential additions, below grade entrances, carports, garages, and pool fence enclosures.
For decks, porches, carports, garages, additions, and below grade entrances, City of Brampton specifically calls for a legal property survey and site plan. For pool fence enclosures, the site plan information may be incorporated into the legal survey.
Create a site plan for free using HomeCat that gets your residential building permit approved in City of Brampton. Get started
Site plan requirements for residential building permits in City of Brampton
The exact City of Brampton requirements depend on the project type, but a useful site plan usually includes:
- Legal property survey as the base when the checklist requires it
- Property lines
- Existing buildings and structures
- Proposed construction, labelled clearly
- Dimensions of existing and proposed construction
- Setbacks from the proposed work to property lines
- Distances from the proposed work to existing buildings
- Existing and final grading for pool fence enclosure applications
- Fence type, gate location, and pool-related measurements when applying for a pool enclosure
Use the City of Brampton permit package for your project first. If it says a copy of a legal survey must accompany the site plan, include the survey in the permit package and draw the proposed work on a copy or clear overlay.
Decks and patios
For decks and patios, City of Brampton asks for a site plan and legal property survey showing the location and dimensions of the proposed deck and the setbacks to the lot line. A copy of the legal survey must accompany the site plan.
Deck site plan example for City of Brampton
Porches and porch enclosures
For a porch or porch enclosure, show the location and dimensions of existing buildings and the proposed porch. Add dimensions from the proposed porch to the lot lines and existing buildings. City of Brampton asks for the legal property survey to accompany the site plan.
Porch site plan example for City of Brampton
Carports and garages
For a carport or garage, show the location and dimensions of the existing buildings and proposed carport or garage. Add dimensions from the proposed structure to the lot lines and existing buildings, and include the legal property survey.
Carport site plan example for City of Brampton
Accessory structures
For sheds, gazebos, cabanas, and other accessory buildings, City of Brampton asks for a site plan showing the proposed accessory building location, dimensions, distance from property lines, and distance from other buildings.
Pool fence enclosures
For a pool fence enclosure, City of Brampton asks for a site plan that may be incorporated into the legal survey. Show measurements from property lines to the water's edge of the pool, with a 1.2 metre minimum, and measurements from the pool enclosure to the water's edge of the pool, also with a 1.2 metre minimum.
Also show existing and final grading, landscape features to be added, the type of fence, self-closing and self-latching gate locations, all buildings, access doors from those buildings, and dimensions from buildings and access doors to the pool's edge.
Pool fence enclosure site plan example for City of Brampton
(With Survey) How to draw a site plan using a survey for City of Brampton
For many City of Brampton residential permits, this is the main method to use. The legal property survey gives you the property lines, house location, and existing measurements that City of Brampton needs to review setbacks and the proposed location.
If you do not have a survey, check your closing documents, ask your real estate lawyer, closing agent, or mortgage company, or request a property survey through City of Brampton Building Records routine disclosure. You can also read our guide for getting a property survey in Ontario before paying for a new one.
1. Print your survey, and get an extra blank piece of paper
Print the survey at a readable size. If possible, keep the scale intact. Get a blank sheet of paper, tracing paper, or a transparent digital layer if you are working on a tablet.
Do not mark up your only original copy. Work on a copy so you can start over if needed.
Example property survey to use as the base drawing
Blank paper, ruler, and pen for drawing over a survey
2. Place the paper over, and trace important details
Trace the property boundary, house footprint, north arrow, street, setback measurements, existing buildings, easements, rights-of-way, and any grading or landscape features that affect the project.
For a pool fence enclosure, also add the pool edge, pool enclosure, fence type, gate locations, access doors from buildings, existing and final grading, and landscape features to be added.
Survey details traced by hand
3. Draw your proposed structures and add measurements and setbacks
Draw the proposed work on the traced survey or survey copy. Label it clearly as proposed and write the dimensions of the proposed work.
Add the setbacks from the proposed work to the lot lines and existing buildings. For decks, porches, carports, garages, and additions, make these dimensions easy to find because City of Brampton's checklists specifically ask for them.
For example, if the survey shows the back wall of the house 9 metres from the rear lot line and the proposed deck is 3 metres deep, the remaining rear setback is about 6 metres. Write that setback directly on the site plan.
Proposed structures drawn on traced survey
Site plan examples for permit for City of Brampton
City of Brampton provides examples for decks, porches, carports, and pool fence enclosures. Use the example that matches your project and copy the level of detail, not the sample dimensions.
Deck site plan example for City of Brampton
Porch site plan example for City of Brampton
Carport site plan example for City of Brampton
Pool fence enclosure site plan example for City of Brampton
Common site plan mistakes that delay your residential building permit in City of Brampton
Most site plan delays come from missing survey information, missing dimensions, or unclear relationships between the proposed work and existing buildings.
Submitting an approximate drawing when a legal survey is required
For decks, porches, carports, garages, additions, and below grade entrances, City of Brampton checklists refer to a legal property survey with the site plan. If your project checklist requires it, include the legal survey instead of only submitting a map screenshot or rough sketch.
Missing setback measurements
Add dimensions from the proposed work to the lot lines. For porches, carports, garages, and additions, also add dimensions to existing buildings on the property.
Missing proposed work dimensions
Write the proposed structure size directly on the drawing. Do not make the reviewer guess the width, length, area, or location of the deck, porch, garage, carport, accessory structure, or below grade entrance.
Missing pool enclosure details
For pool fence enclosures, show the pool edge, pool enclosure, fence type, self-closing and self-latching gates, grading, landscape features, buildings, access doors, and required pool-edge measurements.
Frequently asked questions about site plans
Can homeowners prepare and submit their own drawings in City of Brampton?
Yes. In Ontario, a homeowner can generally prepare drawings for a house they own because the Ontario Building Code exempts design work for "a house owned by the person" from the usual designer qualification requirements under Division C, Article 3.2.5.1.(3)(b)(i). City of Brampton can still require the drawings and survey information needed for permit review.
What if City of Brampton asks me to fill out Schedule 1: Designer Information?
For the design activities section, select House and describe the project, such as "deck," "porch," "garage," "carport," or "pool enclosure."
Under the designer declaration, choose The design work is exempt from the registration and qualification requirements of the Building Code. For the basis of exemption, write Homeowner.
Where can I get a legal property survey in City of Brampton?
Start with your closing documents, then ask your real estate lawyer, closing agent, or mortgage company. If those do not work, request a property survey through City of Brampton Building Records routine disclosure.
Read our Ontario ultimate guide for getting a property survey before paying for a new survey.
Does my survey need to be recent?
An older survey prepared by a licensed Ontario Land Surveyor can still be useful if it accurately shows the property boundaries and existing conditions. Update your site plan so it shows current buildings, decks, patios, driveways, pools, and the proposed work.
What if City of Brampton rejects my site plan?
Read the review comments and revise the drawing to answer each one. Add missing lot-line setbacks, dimensions to existing buildings, legal survey information, grading details, pool enclosure details, or labels as requested.
Can I use Google Maps for my City of Brampton site plan?
Use Google Maps only as a planning reference when you are organizing your project. If City of Brampton's checklist requires a legal property survey, the final permit drawing should be based on that survey.
When do I need a professional drawing?
You may need professional help when the project is structural, engineered, complex, close to regulated areas, or when City of Brampton specifically requires a qualified professional. For location and setback information, start with the legal survey and the project checklist.
Conclusion
A good beginner site plan does not need to be complicated. It needs to show the property, the existing conditions, the proposed work, and the measurements that matter for your residential building permit in City of Brampton.
