If you are applying for a residential building permit in City of Kitchener, the site plan is where the reviewer sees the project in relation to the lot. City of Kitchener lists site-plan items for decks, porches, additions, pools, carports, attached garages, detached garages, accessory structures, sheds, and driveway widening.
This guide explains how to draw a site plan for a residential building permit in City of Kitchener, what details to include for common projects, and how to make a scaled drawing that shows property lines, dimensions, setbacks, and nearby structures clearly.
What is a site plan?
Site plan definition
A site plan is a scaled or clearly dimensioned drawing of your property from above. It shows the property boundaries, existing buildings, proposed work, and distances from the proposed work to property lines and other nearby features.
For a homeowner, the easiest way to think about it is this: a site plan for property shows what is already on the lot and what you want to add or change. A site plan for a residential building permit helps City of Kitchener review deck setbacks, addition location, pool layout, garage placement, shed dimensions, accessory structures, driveway widths, curb cuts, sidewalks, hydrants, utility poles, guy wires, utility boxes, light posts, signs, and municipal trees when those items apply.
City of Kitchener's driveway-widening guidance specifically asks for a scaled drawing in metres with a north arrow. For building permits, the same habit helps: make the drawing measured, labelled, and easy to compare against the permit checklist.
Common site plan terminology
| Term | Plain-English meaning | Example |
|---|---|---|
| Setbacks | The distances from a structure or proposed structure to the property lines. |  Setback example |
| Existing buildings and structures | Things already on the property, such as the house, shed, pool, deck, garage, driveway, walkway, sidewalk, fence, or accessory building. |  Existing structures example |
| Proposed buildings and structures | New items you want approval for, such as a proposed deck, porch, addition, pool, carport, attached garage, detached garage, shed, accessory building, or driveway widening. |  Proposed structures example |
| Dimensions | Measurements written directly on the drawing, including the size of the proposed work and distances to property lines. |  Site plan dimensions example |
| Lot lines or property lines | The legal edges of your property. These are the lines reviewers use when checking setbacks. |  Property line example |
| Lot grading | The shape and slope of the land that controls where water drains on the property. |  Lot grading example |
Do you need a site plan?
You usually need a site plan when your City of Kitchener project adds or changes something outside the house. City of Kitchener asks for site plan information for decks and porches, home additions, pools, carports and attached garages, detached garages and other accessory structures, sheds, and driveway widening.
For most building permit projects, the site plan should show the proposed work, dimensions, distance to property lines, and other structures in the area. For driveway widening, City of Kitchener asks for a scaled drawing in metres showing property lines, the house, existing and proposed driveway widths, curb cut width, walkway width if applicable, sidewalk and curb locations, distances to street fixtures and utilities, and a north arrow.
Create a site plan for free using HomeCat that gets your residential building permit approved in City of Kitchener. Get started
Site plan requirements for residential building permits in City of Kitchener
The exact City of Kitchener requirements depend on the project, but a useful site plan usually includes:
- Property boundaries or property lines
- Existing building or house location
- Other structures in the area, such as sheds, decks, pools, or garages
- Proposed work location
- Proposed work dimensions
- Distance from the proposed work to property lines
- Pool fence locations and fence construction type when applicable
- Existing and proposed driveway widths when applicable
- Curb cut, walkway, sidewalk, and curb locations when applicable
- Distances to hydrants, utility poles, guy wires, utility boxes, light posts, signs, and municipal trees for driveway widening
- North arrow, especially for driveway widening drawings
Use the City of Kitchener guidance for your exact project. A shed site plan is mostly about the shed location, dimensions, setbacks, and nearby structures. A driveway-widening drawing needs municipal frontage details that would not matter for a backyard deck.
Decks and porches
For a deck or porch, show the dimensions of the deck, the distance from the deck to the property lines, and other structures in the area, such as a shed or pool.
Additions
For a home addition, show the property boundaries, existing buildings, other structure locations, the proposed location of the addition, and the dimensions and distance to property lines for the proposed addition.
Pools
For a pool, show the location and configuration of the proposed pool, distance to all property lines and existing building, and fence locations confirming compliance with the fence bylaw, including the type of construction.
Garages, carports, and accessory structures
For a carport or attached garage, show the proposed location, dimensions, distance from the proposed structure to property lines, and other structures in the area.
For a detached garage or other accessory structure, show the proposed accessory building or garage location, dimensions, distance from the building to the property line, and other structures in the area. For a shed, show the proposed shed location, dimensions, distance from the shed to the property line, and nearby structures such as a deck or pool.
Driveway widening
For driveway widening, include a scaled drawing in metres. Show the property lines, house, existing and proposed driveway widths, curb cut width, walkway width if applicable, sidewalk and curb locations, distances to hydrants, utility poles, guy wires, utility boxes, light posts, signs, and municipal trees, plus a north arrow.
(Without Survey) How to draw a scaled site plan by hand for City of Kitchener
For many City of Kitchener homeowner projects, a clean scaled drawing can work when the checklist does not require a survey. Use this method for decks, porches, sheds, garages, accessory structures, additions, and driveway widening when you have reliable measurements. If property lines are uncertain or the project is tight to a setback, use a survey as the base.
1. Draw the footprint of your house
Start with the existing house or building. Draw it large enough that there is room to add the proposed work and the required dimensions.
House footprint drawn by hand
2. Draw your property boundary
Draw the property boundaries or property lines. For driveway widening, use metres and leave enough room to show the curb, sidewalk, walkway, and municipal frontage details.
Property boundary drawn by hand
3. Draw the main street along your property
Show the street, curb, sidewalk, driveway, and walkway when they matter to the project. Add a north arrow, especially for driveway widening.
Main street drawn on hand site plan
4. Label the rear of your property
Label the rear yard or back of the property so the reviewer can quickly understand the orientation of decks, additions, sheds, garages, pools, and accessory structures.
Rear yard labeled on hand site plan
5. Draw existing and proposed structures
Add other structures in the area, such as sheds, decks, pools, garages, and accessory buildings. Then draw the proposed deck, addition, pool, garage, shed, accessory structure, or driveway widening.
Existing and proposed structures drawn by hand
6. Measure setbacks, proposed, and existing structures
Write the proposed work dimensions and distances to property lines. For driveway widening, also add existing and proposed driveway widths, curb cut width, walkway width if applicable, sidewalk and curb locations, and distances to hydrants, utility poles, guy wires, boxes, light posts, signs, and municipal trees.
Measurements added to hand-drawn site plan
Create a site plan for free using HomeCat that gets your residential building permit approved in City of Kitchener. Get started
(With Survey) How to draw a site plan using a survey for City of Kitchener
If you have a property survey, use it as the base for your City of Kitchener site plan. A survey can help with legal property lines, existing building locations, and measured setbacks, especially for additions, garages, sheds, pools, and projects close to a lot line.
If you do not have a survey, check your closing documents, ask your real estate lawyer, closing agent, or mortgage company, or submit a building records request to the City of Kitchener. You can also read our guide for getting a property survey in Ontario before paying for a new one.
1. Print your survey, and get an extra blank piece of paper
Print the survey at a readable size. If possible, keep the scale intact. Get a blank sheet of paper, tracing paper, or a transparent digital layer if you are working on a tablet.
Do not mark up your only original copy. Work on a copy so you can start over if needed.
Example property survey to use as the base drawing
Blank paper, ruler, and pen for drawing over a survey
2. Place the paper over, and trace important details
Trace the property boundary, house footprint, street, existing buildings, and other structures in the area. Add any measurements from the survey that help establish setbacks.
For driveway widening, the survey may not show every municipal frontage feature, so add the curb, sidewalk, walkway, hydrants, utility poles, guy wires, utility boxes, light posts, signs, and municipal trees from field measurements where they apply.
Survey details traced by hand
3. Draw your proposed structures and add measurements and setbacks
Draw the proposed deck, porch, addition, pool, carport, garage, shed, accessory structure, or driveway widening on the survey copy. Label it clearly and write the dimensions.
Add the distance from the proposed work to property lines. For pools, show fence locations and fence construction type. For driveway widening, use metres and include driveway widths, curb cut width, sidewalk and curb locations, frontage obstacles, and a north arrow.
Proposed structures drawn on traced survey
Site plan examples for permit for City of Kitchener
For a City of Kitchener deck or porch, a good example shows the deck dimensions, distance from the deck to property lines, and nearby structures such as a shed or pool.
For an addition, show the property boundaries, existing buildings, other structures, proposed addition location, addition dimensions, and distances to property lines.
For a pool, the drawing should make the pool configuration clear and show distances to all property lines and the existing building. Include fence locations and construction type so the drawing addresses the fence bylaw information City of Kitchener asks for.
For driveway widening, the example should look more like a measured frontage plan: property lines, house, existing and proposed driveway widths, curb cut width, walkway width if applicable, sidewalk and curb locations, distances to hydrants and utilities, municipal trees, signs, light posts, and a north arrow.
Common site plan mistakes that delay your residential building permit in City of Kitchener
Most City of Kitchener site plan delays come from missing dimensions, missing nearby structures, or using a generic drawing that does not match the project type.
Missing dimensions or distances to property lines
City of Kitchener repeatedly asks for dimensions and distances to property lines. Add the size of the proposed deck, addition, garage, shed, pool, or driveway work and the relevant setbacks directly on the drawing.
Missing other structures in the area
For decks, carports, garages, accessory structures, and sheds, show other nearby structures such as decks, pools, sheds, and garages. These help the reviewer understand spacing and the project area.
Missing pool fence details
For pools, show fence locations and include the type of construction. Do not leave the fence bylaw information out of the site plan.
Missing driveway frontage details
For driveway widening, include the scaled drawing in metres, driveway widths, curb cut width, walkway width if applicable, sidewalk and curb locations, north arrow, and distances to hydrants, utility poles, guy wires, boxes, light posts, signs, and municipal trees.
Unclear property boundaries
If you are not sure where the property lines are, do not guess on the final permit drawing. Use a survey, title documents, or other reliable property information before committing to setback measurements.
Frequently asked questions about site plans
Can homeowners prepare and submit their own drawings in City of Kitchener?
Yes. In Ontario, a homeowner can generally prepare drawings for a house they own because the Ontario Building Code exempts design work for "a house owned by the person" from the usual designer qualification requirements under Division C, Article 3.2.5.1.(3)(b)(i). City of Kitchener can still require measured, scaled, and complete drawings for permit review.
What if City of Kitchener asks me to fill out Schedule 1: Designer Information?
For the design activities section, select House and describe the project, such as "deck," "porch," "addition," "pool," "garage," "shed," or "accessory structure."
Under the designer declaration, choose The design work is exempt from the registration and qualification requirements of the Building Code. For the basis of exemption, write Homeowner.
Where can I get a legal property survey in City of Kitchener?
Start with your closing documents, then ask your real estate lawyer, closing agent, or mortgage company. If those do not work, submit a building records request to the City of Kitchener.
Read our Ontario ultimate guide for getting a property survey before paying for a new survey.
Does my survey need to be recent?
An older survey prepared by a licensed Ontario Land Surveyor can still be useful if it accurately shows property boundaries and existing conditions. Update the site plan so it shows current decks, sheds, pools, garages, driveways, sidewalks, curb cuts, accessory structures, and proposed work.
Can I use Google Maps for my City of Kitchener site plan?
Use Google Maps only as a planning reference. City of Kitchener's guidance depends on measured dimensions, distances to property lines, and, for driveway widening, a scaled drawing in metres. Confirm property lines and frontage measurements before submitting.
What if City of Kitchener rejects my site plan?
Read the review comments and revise the drawing to answer each one. Add missing property lines, dimensions, setbacks, nearby structures, pool fence information, driveway widths, curb cut width, sidewalk and curb locations, north arrow, utility distances, or municipal tree details as requested.
When do I need a survey or professional drawing?
Use a survey when the project is close to a lot line, when property boundaries are uncertain, or when accurate setbacks are important for an addition, pool, garage, shed, or accessory structure. You may need professional help for engineered, structural, complex, or non-standard work.
Conclusion
A good beginner site plan does not need to be complicated. It needs to show the property, the existing conditions, the proposed work, and the measurements that matter for your residential building permit in City of Kitchener.
